Digisol DG-GS1528HP User Manual

DG-GS1528HP User Manual
185
• Debug: Provides detailed information about an event.
4.13.2. Mirroring
To view the Mirroring menu, navigate to Diagnostics > Mirroring.
Figure 137 - Diagnostics > Mirroring
Item
Description
Session ID
Select mirror session ID.
State
Select mirror session state : port-base mirror or disable
• Enabled: Enable port based mirror
• Disabled: Disable mirror.
Monitor Port
Select mirror session monitor port, and select whether
normal packet could be sent or received by monitor port.
Ingress port
Select mirror session source rx ports.
Egress port
Select mirror session source tx ports.
Click "Edit" button to view the Edit Mirroring menu.
