DG-GS1528HP User Manual
73
Figure 50 - VLAN > MAC VLAN > MAC Group > Add/Edit MAC
Item
Description
Group ID
Input group ID that is a unique ID of mac group entry.
The range from 1 to 2147483647. Only available on Add
Dialog.
MAC Address
Input mac address for classifying packets.
Mask
Input mask of mac address.
4.5.3.2. Group Binding
This page allow user to bind MAC VLAN group to each port with VLAN ID.
To view the Group Binding Table menu, navigate to VLAN > MAC VLAN > Group
Binding.
