4.5.1.4. Port Setting
This page allow user to configure ports VLAN settings such as VLAN port mode,
PVID etc…The attributes depend on different VLAN port mode.
To view the Membership menu, navigate to VLAN > VLAN > Port Setting.
Figure 43 - VLAN > VLAN > Port Setting
Item
Description
Port
Display the interface.
Mode
Display the VLAN mode of interface.
PVID
Display the Port-based VLAN ID of port.
Accept Frame
Type
Display accept frame type of port.
Ingress Filtering
Display ingress filter status of port.
Uplink
Display uplink status.
TPID
Display TPID used of interface.
Click “Edit” button to Edit Port Setting menu.
