DG-GS1528HP User Manual
172
ICMP Code
Select the type for ICMP code. Only available when
protocol is ICMP.
• Any: All codes are acceptable.
• User Defined: Enter an ICMP code to match.
4.11.5. ACL Binding
This page allow user to bind or unbind ACL rule to or from interface. IPv4 and
Ipv6 ACL cannot be bound to the same port simultaneously.
To view the ACL Binding menu, navigate to ACL > ACL Binding.
Figure 126 - ACL > ACL Binding
Item
Description
Port
Display port entry ID.
MAC ACL
Display mac ACL name that bound of interface. Empty
means no rule bound.
IPv4 ACL
Display ipv4 ACL name that bound of interface. Empty
means no rule bound.
Click "Edit" button to view the Edit ACL Binding menu.
