4.8.5.6. Statistics
The Link Layer Discovery Protocol (LLDP) Statistics page displays summary and
per-port information for LLDP frames transmitted and received on the switch.
To view the Statistics menu, navigate to Discovery > LLDP > Statistics.
Figure 73 - Discovery > LLDP > Statistics
Item
Description
Insertions
The number of times the complete set of information
advertised by a particular MAC Service Access Point
(MSAP) has been inserted into tables associated with the
remote systems.
Deletions
The number of times the complete set of information
advertised by MSAP has been deleted from tables
associated with the remote systems.
Drops
The number of times the complete set of information
advertised by MSAP could not be entered into tables
associated with the remote systems because of insufficient
resources.
Age Outs
The number of times the complete set of information
advertised by MSAP has been deleted from tables
associated with the remote systems because the
information timeliness interval has expired.
