Digisol DG-GS1528HP - 4.10.2.3. Management ACE

DG-GS1528HP User Manual
125
Item
Description
ACL Name
Input MAC ACL name.
Management ACL
ACL Name
Display Management ACL name.
State
Display Management ACL whether active.
Rule
Display the number Management ACE rule of ACL.
4.10.2.3. Management ACE
To view the Management ACE menu, navigate to Security > Management Access
> Management ACE.
Figure 93 - Security > Management Access > Management ACE
Item
Description
ACL Name
Select the ACL name to which an ACE is being added.
Priority
Display the priority of ACE.
Action
Display the action of ACE.
Service
Display the service ACE
Port
Display the port list of ACE
Address / Mask
Display the source IP address and mask of ACE.
Click “Add” button view the Add Management ACE menu.
