DG-GS1528HP User Manual
88
4.7.5. Statistics
To view the Statistics menu, navigate to Spanning Tree > Statistics.
Figure 63 - Spanning Tree > Statistics
Item
Description
Refresh Rate
The option to refresh the statistics automatically.
Receive BPDU
(Config)
The counts of the received CONFIG BPDU.
Receive BPDU
(TCN)
The counts of the received TCN BPDU.
Receive BPDU
(MSTP)
The counts of the received MSTP BPDU.
Transmit BPDU
(Config)
The counts of the transmitted CONFIG BPDU.
Transmit BPDU
(TCN)
The counts of the transmitted TCN BPDU.
Transmit BPDU
(MSTP)
The counts of the transmitted MSTP BPDU.
Clear
Clear the statistics for the selected interfaces
View
View the statistics for the interface.
