DG-GS1528HP User Manual
91
Item
Description
State
Enable/ Disable LLDP protocol on this switch.
LLDP Handling
Select LLDP PDU handling action to be filtered, bridging or
flooded when LLDP is globally disabled.
• Filtering: Deletes the packet.
• Bridging: (VLAN-aware flooding) Forwards the packet to all
VLAN members.
• Flooding: Forwards the packet to all ports
TLV Advertise
Interval
Select the interval at which frames are transmitted. The
default is 30 seconds, and the valid range is 5–32767
seconds.
Holdtime
Multiplier
Select the multiplier on the transmit interval to assign to TTL
(range 2–10, default = 4).
Reinitialization
Delay
Select the delay before a re-initialization (range 1–10
seconds, default = 2).
Transmit Delay
Select the delay after an LLDP frame is sent (range 1–8191
seconds, default = 3).
4.8.1.2. Port Setting
To view the Port Setting menu, navigate to Discovery > LLDP > Port Setting.
