DG-GS1528HP User Manual
12
• IEEE 802.3af/at PoE compliant to simplify deployment and installation
• Supports PoE up to 30W per port with 280W total power budget
• Automatically detects powered devices (PD) and power consumption levels
• IEEE 802.1Q VLAN allows network segmentation to enhance performance and
security
• Supports Access Control List (ACL)
• Switch capacity: DG-GS1528HP: 56Gbps, Forwarding rate: 41.6Mpps
• Supports IGMP Snooping V1 / V2 / V3
• 8K MAC address table and 10K jumbo frames
• 19-inch rack-mountable metal case
1.4. Product Components
1.4.1. Ports
The following view applies to DG-GS1528HP.
1 2
Figure 1 - Front View
No.
Name
Description
1
10/100/1000Mbps
RJ-45 ports
(1~24)
Designed to connect to network devices with a
bandwidth of 10Mbps, 100Mbps or 1000Mbps. Each has
a corresponding 10/100/1000Mbps LED.
