DG-GS1528HP User Manual
72
Item
Description
OUI
Input OUI MAC address. Can’t be edited in edit dialog.
Description
Input description of the specified MAC address to the voice
VLAN OUI table.
4.5.3. MAC VLAN
Use the MAC VLAN pages to configure settings of MAC VLAN.
4.5.3.1. MAC Group
This page allow user to add or edit groups settings of MAC VLAN.
To view the MAC menu, navigate to VLAN > MAC VLAN > MAC Group.
Figure 49 - VLAN > MAC VLAN > MAC Group
Item
Description
Group ID
Display group ID of entry.
MAC Address
Display mac address of entry.
Mask
Display mask of mac address for classified packet.
Click “Add” button or "Edit" button to view Add/Edit MAC menu.
