SFP ports (SFP1,
SFP2, SFP3, and
SFP4)
Designed to install SFP modules and connect to network
devices with a bandwidth of 100/1000Mbps. Each has a
corresponding 100Mbps & 1000Mbps LED.
The following view applies to DG-GS1528HP.
1
Figure 2 - Rear View
No.
Name
Description
1
AC power in
Supports AC 100 – 240V, 50-60Hz.
1.4.2. LED Indicators
The following view applies to DG-GS1528HP.
1 2 3 4
Figure 3 - Front View LED Indicators
No.
Name
Description
1
Power
• Off: power off
• On: power on
