DG-GS1528HP User Manual
Click "Add" button to view the Add ACE menu.
Figure 122 - ACL > MAC ACE > Add ACE
Display the ACL name to which an ACE is being added.
Specify the sequence of the ACE. ACEs with higher
sequence are processed first (1 is the highest priority).
Only available on Add Dialog.
Select the action after ACE match packet.
•
Permit: Forward packets that meet the ACE criteria.
•
Deny: Drop packets that meet the ACE criteria.
•
Shutdown: Drop packets that meet the ACE criteria, and
disable the port from where the packets were received.
Such ports can be reactivated from the Port Settings page.
Select the type for source MAC address.
•
Any: All source addresses are acceptable.
•
User Defined: Only a source address or a range of source
