LOADING LOGOS (MENU SELECT 2)
The user can replace the existing FONT, add up
to six logos, or load optional software from a Data
Flash card, which is plugged into the top of the
print carriage. Select to load logos into the
print head.
This screen will be displayed if the data flash card
is either not present or cannot be read.
CHECK THAT THE DATA FLASH CARD IS
PROPERLY INSTALLED
Displaying the number of logos as indicated in the
pictorial indicates successful loading.
The display indicates the number of logos loaded
for the 1 line or 2 line mode.
LOADING OPTIONS (menu select 3)
Optional software may be added via Data Flash
Card to the basic unit to add features.
NOTE: when optional software is loaded into the system the Data Flash
Card is encoded with the serial number of the unit and is valid only for the
unit in which the software was loaded.
Verify system information by pressing the V key
on the hand held controller keyboard. The LCD
screen will display the software, firmware, serial
number and options enabled. Enabled options
are indicated on the second line as a series of +
characters where the first + indicates option
pack 1, the second + indicates option pack 1.5 the third is option pack 2 and the
last + indicates option pack 3.
EXECUTE LOADER
PLEASE WAIT
EXECUTE LOADER
1=LOAD FONTS
2=LOAD LOGOS
3=LOAD OPTIONS
MEMORY ERROR
NO FLASH CARD
ANY KEY TO EXIT
LOAD RESULTS
2 LINE 1 2 3
1 LINE 1 2 3
ANY KEY TO EXIT
EXECUTE LOADER
1=LOAD FONTS
2=LOAD LOGOS
3=LOAD OPTIONS
CONTROLLER 1.06
PRINTER 2.08K ++++
PRINTER SN284955
ANY KEY TO EXIT
