2 • Description
Doc. 031851-05 12/04 2-5
Main Power Receptacle
The AC power outlet is located directly below the power switch.
USB Port
The USB port provides a connection to the Chromeleon computer. For the
standard Chromeleon system configuration of one ICS-90 connected to a
Chromeleon computer, connect a USB cable between the USB connector
on the ICS-90 and a USB port on the computer. See Section B.4
for
detailed connection instructions.
Link LED
The Link LED indicates the communication status
between the ICS-90 and the Chromeleon computer.
The power supply cord is used as the main disconnect device. Make
sure the socket-outlet is located near the ICS-90 and is easily
accessible.
Le cordon d'alimentation principal est utilisé comme dispositif
principal de débranchement. Veillez à ce que la prise de base soit
située/installée près du module et facilement accessible.
Das Netzkabel ist das wichtigste Mittel zur Stromunterbrechung.
Stellen Sie sicher, daß sich die Steckdose nahe am Gerät befindet und
leicht zugänglich ist.
LED Name Status Description
Link On A link has been established between the ICS-90
and the Chromeleon computer, but no data is
currently being transmitted or received
Flashing A link has been established between the ICS-90
and the Chromeleon computer and data is being
transmitted
Off No link between the ICS-90 and the Chromeleon
computer has been established
Link
