ICS-90 Ion Chromatography System
2-6 Doc. 031851-05 12/04
TTL Output Connector
The TTL output connector allows an AS40 Automated Sampler to receive
TTL signals from the ICS-90. See Section B.17
for installation
instructions.
Tubing Connections
Eight lines exit the ICS-90 from the lower left corner of the rear panel.
These lines include:
• 1 eluent line
• 1 regenerant line
• 1 cell outlet line
• 2 air lines
• 3 waste lines (sample, regenerant, and pump priming waste)
