ICS-90 Ion Chromatography System
3-12 Doc. 031851-05 12/04
• For automatic sample processing (see Section 3.5.5), Chromeleon
pauses at the start of the program to allow you to load the sample
loop (Steps 1 through 3 above). After loading the loop, click OK.
Chromeleon automatically switches the injection valve position
and continues running the program.
Injection via the AS40 Automated Sampler
1. Verify that the AS40 output line is connected to port S (5) of the
ICS-90 injection valve, and the
LOAD connector from the AS40 Relay
Control cable is connected to the ICS-90
TTL Output connector on
the rear panel. See Section B.17
for detailed installation instructions.
2. The injection process depends on how you are processing samples:
• For manual sample processing (see Section 3.5.4), load the
injection valve sample loop as instructed in the AS40 Automated
Sampler Operator’s Manual (Document No. 034970). Then, click
the
Inject button on the Chromeleon Control panel (see
Figure 3-3
) to start the injection.
• For automatic sample processing (see Section 3.5.5), the
Chromeleon program contains commands that start the AS40
sample load cycle and switch the ICS-90 injection valve position.
