Distech Controls ECL-PTU Series User Manual

95ECL-PTU-207 Preloaded Applications
Heating Valve Configuration
SystemType (EC6) HeatValveType (EnumCon-
stant8)
CoolValveType (EnumCon-
stant7)
Heating Valve Output
Heat/HeatElectHeat
or
CoolHeat/CoolHeatElectHeat
Unused - Unused
0-10V - AO10
Thermal - DO6
On/Off - DO6
Floating
Floating Invalid Configuration
Not Floating DO5:Open, DO6:Close
Any other settings Unused Unused
Change-Over Valve Configuration
SystemType (EC6) CoolValveType (EnumConstant7) Change-Over Valve Output
ChgOver or ChgOverElectHeat
Unused Unused
0-10V AO9
Thermal DO5 and AO9
On/Off DO5 and AO9
Floating DO5:Open, DO6:Close
Any other settings - Unused
Tables of IO Assignments
