Distech Controls ECL-PTU Series User Manual

31ECL-PTU-207 Preloaded Applications
nvoEffectSetpt (nvoFP01)
This output network variable is used to monitor the effective temperature setpoint that may depend on
nciSetpoints, nvoEffectOccup, nviSetpoint, nviSetpointOffset, nviHeatCool, and any local setpoint ad-
justment.
For example, if the occupancy state is unoccupied and the heat/cool state is heat, then the effective
setpoint would be equal to the unoccupied heating setpoint defined in nciSetpoints.
ID Units Valid Range Default Value
nvoFP01 SNVT_temp_p N/A N/A
nvoEffectOccup (nvoFP02)
This output network variable is used to indicate the actual occupancy mode of the unit.
This information is typically reported to a supervisory controller, or provided to another Space Comfort
Controller to coordinate the operation of multiple units.
The occupancy mode is determined by a combination of optional input network variables and logic in
the controller. See Occupancy Control section for more information.
ID Units Valid Range Default Value
nvoFP02 SNVT_occupancy N/A N/A
nvoHeatCool (nvoFP03)
This output network variable is used to indicate the actual heat/cool mode of the unit.
This information is typically reported to a supervisory controller, or provided to another Space Comfort
Controller to coordinate the operation of multiple units.
When nviApplicMode is equal to AUTO or NUL, nvoHeatCool mode is set by the controller based on
the heating/cooling demand.
When nviApplicMode is not equal to AUTO or NUL, nvoHeatCool is equal to nviApplicMode.
When the space temperature is below the frost protection setpoint, nvoHeatCool is equal to
HVAC_EMERG_HEAT.
ID Units Valid Range Default Value
nvoFP03 SNVT_hvac_mode N/A N/A
nvoFanSpeed (nvoFP04)
This output network variable reflects the actual fan speed control command.
See Fan Control Section for more information.
Fan Status State Value
Off 0 n/a
Between 1% and 100% 1 >0%
ID Units Valid Range Default Value
nvoFP04 SNVT_switch N/A N/A
nvoDischargeAirTemp (nvoFP05)
This output network variable is used to display the actual discharge air temperature sensor value.
ID Units Valid Range Default Value
nvoFP05 SNVT_temp_p N/A N/A
Variables
