Distech Controls ECL-PTU Series User Manual

90 ECL-PTU-207 Preloaded Applications
Tables of configuration codes
System Type
Parameter Default Valid
Choices
Description
TYPE
(EC6)
0 CL 2 Pipes cooling
1 CL-EH 2 Pipes cooling with electric heater
2 HT 2 Pipes Heating
3 HT-EH 2 Pipes Heating with electric heater
4 CO 2 Pipes Change Over
5 CO-EH 2 Pipes Change Over with electric heater
X 6 CL-HT 4 Pipes
7 CL-HT-EH 4 Pipes with electric heater
Fan Type
Parameter Default Valid
Choices
Description
FT
(nviFP39)
0 NONE Fan control is not used
1 1 SP 1-Speed fan
2 2 SP 2-speed fan
3 3 SP 3-speed fan
X 4 ECM ECM motor (0-10V output)
Table20: Fan Ctrl Type
Fan Mode
Parameter Default Valid
Choices
Description
FAN (nviFP39)
0 ON Fan is controlled between minimum speed and 100%
1 AUTO Fan control is based on terminal load
X 2 SMART
Fan control is based on terminal load when unoccupied,
and between minimum speed and 100% in other
occupancy modes.
3 AUTO HEAT Fan control is based on heaing load
4 AUTO COOL Fan control is based on cooling load
Table21: Fan Mode
