Distech Controls ECL-PTU Series - HVAC Bindings

48 ECL-PTU-207 Preloaded Applications
nvoFanSpeedCmd
Using nvoFanSpeedCmd, the master send FanSpeedCmd (override) value to every slave via nvi-
FanSpeedCmd.
Figure10: nvoFanSpeedCmd
HVAC Bindings
Using nvoUnitStatus, the master send every HVAC value (Fanspeed, Valves, Damper, Hvaec Mode
and Electric heater).
This enables all the units to work based on the control signal of the master.
Figure11: HVAC-Bindings
Master/Slave Control
