Distech Controls ECL-PTU Series User Manual

94 ECL-PTU-207 Preloaded Applications
Tables of IO Assignments
Fan Configuration
nciFanSettings.FanC-
trlType (nviFP39)
Variable Fan FanSpeed1 FanSpeed2 FanSpeed3
None Unused Unused Unused Unused
1Speed Unused DO1 Unused Unused
2Speed Unused DO1 DO2 Unsued
3Speed Unused DO1 DO2 DO3
VarSpeed AO7 DO1 Unused Unused
Electric Heater Configuration
SystemType (EC6) Electric Heater Output
Cool Unused
CoolElectHeat DO4
ChgOver Unused
ChgOverElectHea DO4
Heat Unused
HeatElectHeat DO4
CoolHeat Unused
CoolHeatElectHeat DO4
Damper Configuration
DamperCtrlType (EnumCon-
stant9)
Damper Output
None Unused
0-10V AO8
2-10V AO8
Cooling Valve Configuration
SystemType (EC6) CoolValveType (EnumConstant7) Cooling Valve Output
Cool/CoolElectHeat
or
CoolHeat/CoolHeatElectHeat
Unused Unused
0-10V AO9
Thermal DO5 and AO9
On/Off DO5 and AO9
Floating DO5:Open, DO6:Close
Any other settings - Unused
Tables of IO Assignments
