Distech Controls ECL-PTU Series User Manual

27ECL-PTU-207 Preloaded Applications
nciMiscConfig (nviFP44)
This configuration property defines miscellaneous configurations for the HVAC control functions.
Field Description
SI3Config This configuration is used to configure sensor type link to SI3 input.
SpOffsetLimit Setpoint Offset Limit for EC-Remote remote control and EC-Smart-Vue
SpaceTempOffset Space Temperature Calibration Offset
DischTempOffset Discharge Temperature Calibration Offset
ReturnTempOffset Return Temperature Calibration Offset
MinDischAirSP Minimum Discharge Temperature Setpoint Limitation
MaxDischAirSP Maximum Discharge Temperature Setpoint Limitation
FrostProtSp Frost Protection Setpoint
DischAirLimitType Discharge temperature limitation type
ChgOverDelay Change Over Delay between Heat/Cool Mode
MotionHoldTime Motion Hold Time Delay (Delay is divided by 3 when BMS is in Unoccupied Mode)
BypassTime Bypass Time from Occupany Push Button or EC-Smart-Vue
Sensor1Zone EC-Multi-Sensor #1 Infrared Zone Number
Sensor2Zone Unused
SheddingOnSetpoint Enable Shedding via Setpoints Offset or via direct load shedding
SheddingEnabled Enable Shedding Commands for HVAC equipment
Field Min Value Max Value Default Value
SI3Config 0 (SpaceTemp) 4 (Other) 0
SpOffsetLimit 0°C 10°C 3°C
SpaceTempOffset -10°C 10°C 0°C
DischTempOffset -10°C 10°C 0°C
ReturnTempOffset -10°C 10°C 0°C
MinDischAirSP 5 °C 20 °C 13°C
MaxDischAirSP 20 °C 45 °C 35°C
FrostProtSp 2 °C 15 °C 8 °C
DischAirLimitType 0 3 0(Not Limited)
ChgOverDelay 0 min 30 min 1 min
MotionHoldTime 1 min 120 min 15 min
BypassTime 0 min 360 min 60 min
Sensor1Zone 0 30 0
Sensor2Zone 0 30 0
SheddingOnSetpoint 0 1 0
SheddingEnabled 0 1 1
Reserved1 0 1 1
Reserved2 0 1 0
Reserved3 0 1 0
Reserved4 0 1 0
Reserved5 0 1 0
Reserved6 0 1 0
ID Units Default Value
nviFP44 UNVT_Misc_Config_PTU N/A
