33ECL-PTU-207 Preloaded Applications
nvoReturnTemp (nvoFP12)
This output network variable is used to monitor the temperature of the air that enters the Space Com-
fort Controller, if the input SI3 is linked to the return air temperature custom block. If not used, this vari-
able output is 327.67°C.
ID Units Valid Range Default Value
nvoFP12 SNVT_temp_p N/A N/A
nvoFanSpeedCmd (nvoFP13)
This output network variable will output the actual fan speed command override of the unit.
When nviFanSpeedCmd is valid (State between 0 and 1), nvoFanSpeedCmd equals nviFanSpeed-
Cmd. Otherwise, nvoFanSpeedCmd is linked with the local fan speed override of the EC-Remote, the
EC-Smart-Vue or the EC-Smart-Comfort.
Fan Override State Value
Auto -1 n/a
Off 0 n/a
Low 1 33%
Med 1 66.50%
High 1 100%
Fan Override State Value Fan Override
Auto -1 n/a Auto
nvoSourceTemp (nvoFP14)
This output network variable is used to monitor the temperature of the source temperature.
If nviSourceTemp is valid, nvoSourceTemp will use this value.
If nviSourceTemp is invalid, nvoSourceTemp will be equal to a local input, if configured.
If not used, this variable output is 327.67°C.
ID Units Valid Range Default Value
nvoFP14 SNVT_temp_p N/A N/A
nvoEffectCoolSp (nvoFP15)
This output network variable is used to monitor the effective cooling setpoint.
ID Units Valid Range Default Value
nvoFP15 SNVT_temp_p N/A N/A
nvoEffectHeatSp (nvoFP16)
This output network variable is used to monitor the effective heating setpoint.
ID Units Valid Range Default Value
nvoFP16 SNVT_temp_p N/A N/A
nvoEffectHeatSp (nvoFP16)
This output network variable is used to monitor the effective heating setpoint.
ID Units Valid Range Default Value
nvoFP16 SNVT_temp_p N/A N/A
