Distech Controls ECL-PTU Series User Manual

40 ECL-PTU-207 Preloaded Applications
Sequence of Operation
Occupancy Control
The nvoEffectOccup (nvoFP02) is managed based on nviSchedule and RoomOccupancy (BV2)
The nviSchedule is usually received from the network and the RoomOccupancy (BV2) is based on
motion detection and occupancy overrides.
The following table describes the sequence of operation for the occupancy control:
nviSchedule RoomOccupancy (BV2) nvoEffectOccup (nvoFP02)
Occupied
Occupied Occupied
Unoccupied Standby
Unoccupied
Occupied Occupied
Unoccupied Unoccupied
Bypass
Occupied Occupied / Bypass
1
Unoccupied Standby
Standby
Occupied Occupied
Unoccupied Standby
Table2: Occupancy Control
1. If no motion is connected and schedule is unoccupied, the bypass mode is activated for 60 min-
utes if the room occupancy is set to occupied (EC-Smart-Vue, EC-Smart-Sensor and EC-Smart-
Comfort).
Motion Hold Time
After the last occupancy detection, RoomOccupancy (BV2) is maintained to OCCUPIED for 15 min-
utes (motion hold time default value). If no detection happens during this periodnvoEffectOccup
(nvoFP02) is set to STANDBY (if nviSchedule = OCCUPIED) or UNOCCUPIED (if nviSchedule = UN-
OCCUPIED). When nviSchedule is UNOCCUPIED, this motion hold time is divided by 3.
Temperature Setpoint Control
The actual setpoints nvoEffectHeatSp and the nvoEffectCoolSp are computed according to nvoEffec-
tOccup (nvoFP02)nvoSetPtOffset
nvoEffectOccup (nvoFP02) nvoEffectHeatSp nvoEffectCoolSp
Occupied or Bypass
OccHeatSP (nciSetpoints) +
nvoSetPtOffset
OccCoolSP (nciSetpoints) +
nvoSetPtOffset
Standby
StandbyHeatSP (nciSetpoints) +
nvoSetPtOffset
StandbyCoolSP (nciSetpoints) +
nvoSetPtOffset
Unoccupied UnoccHeatSP (nciSetpoints) UnoccCoolSP (nciSetpoints)
Table3: Actual setpoints values
The effective setpoint nvoEffectSetpt is computed according to HvacModeStatus:
HvacModeStatus value nvoEffectSetpt
Heat or Off nvoEffectHeatSp
Cool nvoEffectCoolSp
Table4: Effective setpoint value
Sequence of Operation
