26 ECL-PTU-207 Preloaded Applications
nciDamperSettings (nviFP40)
This configuration property defines the different configuration of the air quality damper.
Field Description
outdoorCO2Offset
This configuration is used to calculate the effective Space CO2 setpoint when nviOutdoorCO2
is used.
minPositionOcc This configuration is used to set the minimum damper position in occupied mode.
minPositionStby This configuration is used to set the minimum damper position in standby mode.
maxPosition This configuration is used to set the maximum allowable damper position.
Reserved1 This configuration is not used in this program.
Reserved2 This configuration is not used in this program.
Field Name Min Value Max Value Default Value
outdoorCO2Offset 100 ppm 2000 ppm 600 ppm
minPositionOcc 0% 100% 10%
minPositionStby 0% 100% 5%
maxPosition 0% 100% 100%
Reserved1 0% 100% 0%
Reserved2 0% 100% 0%
ID Units Default Value
nviFP40 UNVT_Damper_settings N/A
nciHVACScaling (nviFP41)
This configuration property can be used to rescale the heating cooling load of the different equip-
ments.
Field Description
minCoolingValve
This configuration is used to select the cooling load value before starting the cooling valve
operation.
maxCoolingValve
This configuration is used to select the cooling load value at which the cooling valve will be
at 100% operation.
minHeatingValve
This configuration is used to select the heating load value before starting the heating valve
operation.
maxHeatingValve
This configuration is used to select the heating load value at which the heating valve will be
at 100% operation.
minElectHeater
This configuration is used to select the heating load value before starting the electric heater
operation.
maxElectHeater
This configuration is used to select the heating load value at which the electric heater will be
at 100% operation.
Field Name Min Value Min Value Default Value
Default Value Default Value Default Value Default Value
Default Value Default Value Default Value Default Value
Default Value Default Value Default Value Default Value
Default Value Default Value Default Value Default Value
Default Value Default Value Default Value Default Value
Default Value Default Value Default Value Default Value
ID Units Default Value
nviFP41 UNVT_hvac_scaling N/A
