116 ECLYPSE Connected Thermostat (ECY-STAT)
Fan Control
The main fan settings can be controlled here. The center graphic displays the current fan speed set-
ting.
Depending on the programming with EC-
gfx
Program, Fan Control will be displayed in either Level or
Analog mode. Shown below is Level mode.
Icon Description
Tap and hold the slider icon to adjust the fan speed. Alternatively, you can tap a position on the slider to
jump to that position.
Auto OFF / ON
The Auto icon toggles automatic mode ON. To turn Auto mode OFF, adjust the fan speed slider. The auto
function parameters are configured using EC-
gfx
Program. See the EC-
gfx
Program User Guide for more
information.
