118 ECLYPSE Connected Thermostat (ECY-STAT)
Sunblind Groups
Up to eight sunblind groups can be used. The sunblind groups must first be programmed using EC-
gfx
Program and enabled or disabled using the ECLYPSE Web Interface. See the ECLYPSE User
Guide and the EC-
gfx
Program User Guide for more information.
Depending on the programmed configuration of the sunblind groups, different options will be available
for each group which are outlined below.
Icon Description
Auto OFF / ON
The Auto icon toggles automatic mode ON. To turn Auto mode OFF, adjust the sunblind slider or the
rotational angle. The auto function parameters are configured using EC-
gfx
Program. See the EC-
gfx
Program User Guide for more information.
CLOSED / OPEN
Tap the sunblind icons to instantly jump to the fully closed or fully open levels that are configured for that
group.
Tap and hold the slider icon to adjust the position of the sunblinds. Alternatively, you can tap a position on
the slider to jump to that position.
Tap to select the desired sunblind rotational angle between 0 and 180 degrees.
Navigating the User Interface
To Next Page
