Simga2N Traction Advanced Manual– V1.3 Page 65 (166) ©2021 DMC GmbH Herten Germany
M1.6-7 Wig/Wag forward threshold ”FwdTH”
This parameter is active if the parameter “M1.6-2 Accelerator type ”AccelTyp””, in the Controller Set-up menu,
is set to 1.
This value sets the voltage on “Pin A9 Analogue AD1 i/p Accelerator -- Potentiometer” on 35-way connector
from which forward drive commences. Together with “M1.6-8Wig/Wag reverse threshold ”RevTH”, this
parameter forms a ‘dead band’ in which the wig-wag assumes a neutral position.
M1.6-8 Wig/Wag reverse threshold ”RevTH”
This parameter is active if the parameter “M1.6-2 Accelerator type ”AccelTyp””, in the Controller Set-up menu,
is set to 1.
This value sets the voltage on “Pin A9 Analogue AD1 i/p Accelerator -- Potentiometer” on 35-way connector
from which reverse drive commences. Together with “M1.6-7 Wig/Wag forward threshold ”FwdTH””, this
parameter forms a ‘dead band’ in which the wig-wag assumes a neutral position.
