Standby Battery Power Calculations Standby Current Alarm Current
710 Bus Splitter/Repeater Module Qty _______ x 19 mA ______ Qty _______ x 19 mA ______
711/711S Zone Expansion Module
Active Zone (EOL Installed)
Qty _______
Qty _______
x
x
7 mA
1 mA
______
______
Qty _______
Qty _______
x
x
7 mA
1 mA*
______
______
714 Zone Expansion Module
Active Zones (EOL Installed)
Qty _______
Qty _______
x
x
4 mA
1 mA
______
______
Qty _______
Qty _______
x
x
4 mA
2 mA*
______
______
714-8, 714-16 Zone Expansion Module
Active Zones (EOL Installed)
Qty _______
Qty _______
x
x
12 mA
1 mA
______
______
Qty _______
Qty _______
x
x
12 mA
1 mA*
______
______
715 Zone Expansion Module
Active Zones (EOL Installed)
2-Wire Smokes
Qty _______
Qty _______
Qty _______
x
x
x
4 mA
2 mA
.1 mA
______
______
______
Qty _______
Qty _______
Qty _______
x
x
x
4 mA
34 mA*
18 mA
______
______
______
715-8, 715-16 Zone Expansion Modules
Active Zones (EOL Installed)
2-Wire Smokes
Qty _______
Qty _______
Qty _______
x
x
x
12 mA
2 mA
.1 mA
______
______
______
Qty _______
Qty _______
Qty _______
x
x
x
12 mA
34 mA*
18 mA
______
______
______
716 Output Expansion Module
Active Form C Relays
Qty _______ x 4 mA ______ Qty _______
Qty _______
x
x
4 mA
17 mA
______
______
2W-BLX, 2WT-BLX Smoke Detectors Qty _______ x 9 mA ______ Qty _______ x 21 mA* ______
COSMOD2W Module Qty _______ x 27 mA ______ Qty _______ x 104 mA*# ______
COSMO-2W Smoke and CO Detectors Qty _______ x .6 mA ______ Qty _______ x 30 mA*# ______
572 Indicator LED Qty _______ x 12 mA ______ Qty _______ x 12 mA ______
Aux. Powered Devices on Terminals 7 and 11
Other than Keypads and LX-Bus Modules
______mA ______mA
Sub-Totals this page Sub-Total Standby ______ mA Sub-Total Alarm ______mA
Sub-Totals from previous page Sub-Total Standby ______ mA Sub-Total Alarm ______mA
*Based on 10% of active zones in alarm Total Standby ______ mA Total Alarm ______mA
# For systems that are not Central Station monitored, multiply alarm current by 12.
Total Standby ______ mA x number of Standby Hours needed _____= _____ mA-hours
Total Alarm ______ mA x number of Alarm Hours needed _____ = _____ mA-hours
UL 864 requires 5 minutes (.0833 hours) in Alarm Total _____ mA-hours
Add 10% for battery derating = _____ Amp-hrs Required
1
Based on10% of active zones in alarm.
2
For systems that are not central station monitored, multiply alarm current by12.
* Where h = hours of alarm. For example, a 15 minute alarm = 0.25 h.
