XF6 Series Installation and Programming Guide Digital Monitoring Products
37
This output (1 to 6, 500-599, G01-G20 for XF6-100 panels, 1 to 6, 500-999, G01-G20 for
XF6-500 panels) is turned on any time a Fire, Supervisory , Fire Verify, or Carbon Monoxide
(CO) zone is placed in alarm. The output is turned o by any of the following actions:
• When the User Menu Alarm Silence function is performed.
• When a valid user code is entered to silence the bell.
• When the Silence key is pressed on the 630F Remote Fire Command Center.
• Using the Outputs On/O function in the User Menu.
• The expiration of the Bell Cuto time.
This output can be connected to a lamp, LED, or buzzer using the DMP Model 716 Output
Expansion Module.
Expander Serial Number
If using a 711S Zone Expansion Module, enter the 10 character serial number found on the
module. Press CMD to move to the next prompt.
Already In Use displays when the serial number is already programmed for another zone.
The programmed zone number displays.
Next Zone
Select YES to terminate zone programming. The display returns to Zone Number, allowing
you to enter a new zone number. Select NO to make alter ations to the Alarm Action for a
zone.
To program zones for wireless operation, select NO at the NEXT ZONE - NO YES option.
The WIRELESS NO YES option displays. If the zone you are programming is intended for
wireless devices, select YES. Select NO to continue programming non-wireless zones in the
500 to 999 range.
• Zones 500 through 599 can be programmed for DMP 1100 Series Wireless on an
XF6-100 Series panel
• Zones 500 through 999 can be programmed for DMP 1100 Series Wireless on an
XF6-500 Series panel
Wireless
Select YES to program this zone as a DMP wireless zone. You must program the wireless
House Code prior to adding DMP wireless zones to the system.
See House Code programming in System Options. Default is NO.
Serial Number Entry
Enter the eight-digit serial number found on the DMP wireless device.
Already In Use displays when the serial number is already programmed for another zone.
The programmed zone number displays.
Contact
Transmitter Contact displays if the serial number entered is for an 1103Universal Transmitter.
Press any select key or area to select the contact.
Select INT to use the internal reed switch contacts. Select EXT to connect an external
device to the 1103 terminal block. Default is INTERNAL.
By allowing both of the transmitter contacts (INT and EXT) to be used at the same time,
two zones may be programmed from one transmitter. When using both contacts, you must
use consecutive zone numbers. The same serial number is used for both zones.
The same serial number is used for all four contacts. Select the contact number to
EXPANDER SERIAL #:
NEXT ZN? NO YES
ZONE INFORMATION
WIRELESS? NO YES
TRANSMITTER
SERIAL#: XXXXXXXX
TRANSMITTER
CONTACT: XXXXXXXX
TRANSMTR CONTACT
INT EXT
TRANSMTR CONTACT
1 2 3 4
