Digital Monitoring Products XF6 Series Installation and Programming Guide
44
communication type is DD or NET, the system sends a System Test Begin report to the
central station. After four seconds, the keypad displays the zone type choices for testing.
Zone Types
Select the zone type you want to test. An asterisk next to the zone type indicates the zone
type chosen for testing. Press the select key or area again to deselect the zone type. When
you have selected all the zone types you want for testing, press CMD to display the next
Walk Test option.
FI (Fire zones) - Select FI to test hardwired fire zones. Includes all FI and FV zones.
SV (Supervisory zones) - Select SV to test hardwired supervisory zones. Includes all SV
zones.
Carbon Monoxide (CO) - Select CO to test hardwires carbon monoxide zones.
During the Walk Test, trip each zone device or button on the system for 1 to 2 seconds.
WLS (Wireless Check-in Test) - Select WLS to automatically test wireless transmitter
communications. Includes all wireless devices transmitters programmed for a supervision
time of 0 (zero).
Bell Action
This option selects the bell output action when a zone under test faults. This option
allows the panel bell, and/or fire bell to turn ON and then OFF each time a zone is tripped
(opened or shorted).
NO - Select NO for no bell output action during Walk Test.
YES - Select YES to turn on any bell output for 2 seconds during Walk Test.
PULS - Select PULS to turn on any bell output for 1/4 second during Walk Test. Any LX-Bus
device output turns on for 1.6 seconds due to the polling cycle.
Trip Counter For Walk Test
Once in the Walk Test, walk around and trip each protective device. Continue tripping
devices until the entire system is tested.
With each zone trip during the Walk Test:
• Keypad display increments each time a selected zone is opened or shorted
• The keypad buzzes for two seconds
• The panel sounds the alarm bells as programmed in Bell Action
• Each time a FI, FV, or SV zone trips, a Sensor Reset occurs.
If ENHANCED ZONE TEST is selected as YES:
A Verify message is sent at the time the zone trip occurs instead of at the end of the Walk
Test.
For FI, FV, SV, or CO zone types, the Verify message is sent at the initial trip.
For all other zone types, the Verify message is sent when the zone restores. This allows the
Central Station to count the number of devices per zone.
END - Select END to stop the Walk Test. When the Walk Test ends or a 20-minute time-out
expires, a final Sensor Reset occurs. The System Test End message is sent to the receiver
along with Verify and Fail messages for each zone under test. Faulted zones then display
on the keypad.
Trip Counter For DMP Wireless Check-in Test (WLS)
Displays the number of wireless zones that automatically communicate a supervisory
check-in message. The test will run for a total of 5 minutes. During the 5 minutes the
transmitters are being tested multiple times. At the end of the 5 minutes the results will be
displayed. A timer will be displayed at the keypad to indicate that the test is in progress.
In order for a transmitter to pass it must have checked in 3 or more times. The results will
display which transmitters have failed the test.
• The number of zones that check in. (CC in the example).
• The total number of wireless zones programmed for supervision that should check in.
(TT in the example).
FI SV CO
WLS
BELL NO YES PULS
TRIPS: XXX END
IN PROGRESS XMIN
CHECKIN: CC/TT END
