Select END to stop the Wireless Test. When the test ends or a 5-minute time-out
expires, normal wireless zone processing returns. If all transmitters check-in, both numbers
match within five (5) minutes. If a transmitter has multiple zones (1101, 1114, etc.), all zones
are included in the counts. Failed wireless zones display on the keypad.
Test End Warning
When five minutes remain on the 20 minute Walk Test timer, the keypad displays TEST
END WARNING. If no additional test zone trips occur, the test ends and a final Sensor
Reset automatically occurs. The System Test End message is sent to the receiver along with
Verify and Fail messages for each zone under Walk Test. Faulted zones then display on the
keypad.
Failed Zones Display
For each zone that did not trip (failed), at least once during the Walk Test, all keypads with
matching Display Areas display the zone name and number and buzz for one second. Any
selected (*FI *CO *SV) 24-hour zone that is faulted at the end of the Walk Test displays a
trouble condition for that zone regardless of
the message programmed for the open or short condition of the zone and a zone trouble is
sent to the receiver. Press CMD to display the next failed zone.
For the Wireless Check-in Test, failed wireless zones display only on the keypad. Zone
Verify/Fail reports are not sent to the central station receiver for the wireless check-in test.
KEYPAD SPEAKER OPERATION
When using LCD Keypads, the panel provides distinct speaker tones from the keypad for Fire, Zone Monitor, and Prewarn
events. The list below details the conditions under which the speaker is turned on and o for each event.
Fire On - Fire zone alarm and Bell Output or Fire Bell Output is ON.
O - Alarm Silence.
CO On - CO zone alarm and Bell Ouput are ON.
O - Using Sensor Reset option while no additional CO type zones are in alarm.
WIRELESS CHECK-IN AND SUPERVISION DEFINITIONS
DMP 1100 Series Supervision Time Explained
The supervision time programmed for DMP 1100 Series wireless is the number of minutes that must elapse before a
transmitter missing message is generated for a transmitter that is not sending its automatically generated supervision
message. The supervision time is programmable to 3, 60, 240 minutes. Selecting 0 (zero) disables supervision time.
ZONE TYPE DESCRIPTIONS
This section describes applications for the default Keypad and LX-Bus zone types in Zone Information programming.
FI (Fire zone)
Used for any type of powered or mechanical fire detection device. Typical applications are for smoke detectors, sprinkler
flowswitches, manual pull stations, and beam detectors. Retard, cross zoning, and presignal options are available for the
CKIN:XXX/ZZZ END
TEST END WARNING
ZONE: 10 -FAIL
SOUTH LOBBY
To Next Page
