XF6 Series Installation and Programming Guide Digital Monitoring Products
23
Network Options are provided to define the network configuration for the panel. This information will be used during
communication of messages via network.
IP addresses and port numbers may need to be assigned by the network administrator. When entering an IP, Gateway, or
Subnet Mask address be sure to enter all 12 digits and leave out the periods.
DHCP
If the panel uses a dynamic IP address select YES. When set to YES, the panel operates
using DHCP and does not use the Local IP Address number. When the DHCP option is set
to NO, the panel uses the IP address entered in Local IP Address. The default value for
DHCP mode is YES.
Local IP Address
Enter the local IP address for the panel. The Local IP Address must be unique and cannot
be duplicated. The default local IP address is 192.168.0.250.
Gateway Address
Enter the local gateway address. The Gateway IP Address is needed to exit your local
network. The default gateway address is 192.168.0.1.
Subnet Mask
Enter the local subnet mask assigned to the panel. The default subnet mask address is
255.255.255.000.
DNS Server
Enter the IP address of the DNS (Domain Name System) used by the panel to resolve
domain names into IP addresses. The default address is 192.168.0.1.
On systems with hardwired network connection, the DNS address can be changed even if
the panel has DHCP enabled.
DEVICE SETUP
Device Setup
DHCP NO YES
LOCAL IP ADDRESS
192 .168.0.250
GATEWAY ADDRESS
192 .168.0.1
SUBNET MASK
255.255.255.000
DNS SERVER
192.168.0.1
DEVICE SETUP
To Next Page
