XF6 Series Installation and Programming Guide Digital Monitoring Products
31
Bell Cuto Time
Enter the maximum time from 0 to 99 minutes the Bell Output remains on. Enter 0 (zero)
to provide continuous bell output. The default is 15 minutes.
NAC 1 Sync Protocol
If NAC 1 is programmed to use DMP, it will follow the BELL ACTIONS programmed.
Otherwise, it will perform the sync protocol selected for Fire only. Programming options
are DMP, GENTEX (GEN), System Sensor (SS), and Wheelock (WHLK) Default is DMP.
NAC 2 Sync Protocol
If NAC 2 is programmed to use DMP, it will follow the BELL ACTIONS programmed.
Otherwise, it will perform the sync protocol selected for Fire only. Programming options
are DMP, GENTEX (GEN), System Sensor (SS), and Wheelock (WHLK) Default is DMP.
Default is DMP.
Selective Silence
This prompt will only display when either NAC 1 or NAC 2 is programmed to something
other than DMP. Selective Silence allows the bell and strobe function of the field device to
be turned o separately. Default is YES.
If Selective Silence is set to No; the Alarm Silence would then turn o both strobes and
bells/horns tied to NAC1/2 using the sync protocol.
If Selective Silence is set to Yes; the Alarm Silence would turn o Bells/Horns only; and
Sensor Reset would then turn o the Strobes after the Alarm silence has occurred.
Bell Output
Enter the output/Favorite number when needed to follow the panel Bell Output operation
for all action and o conditions. Enter 0 (zero) to disable.
Bell Action
This section defines the type of Bell Output for zone alarms. Press CMD to display the
default Bell Output for each zone type. Press any select key or area and enter S for a
Steady Bell Output, P for a Pulsed output, T for a Temporal Code 3 output, 4 for a Temporal
Code 4 output, and N for no Bell Output (default). Enable this feature to latch a bell action
to a keypad. Trouble conditions do not activate the Bell Output.
Fire Bell Action
Defines Bell Action for Fire Type zones. The default is T.
Supervisory Bell Action
Defines Bell Action for Supervisory Type zones. The default is N.
Carbon Monoxide (CO)
Defines Bell Action for Carbon Monoxide (CO) Type Zones. The default is set at 4.
OUTPUT OPTIONS
Output Options
This section allows you to program panel output options. The panel provides two Form
C relays (1 and 2) and four switched ground (open collector) outputs numbered 3 to 6.
Expand the system up to 500 additional relay outputs using any LX-Bus on the panel, or
BELL CUTOFF: 15
NAC 1:
DMP GEN SS WHLK
NAC 2:
DMP GEN SS WHLK
SELECTIVE
SILENCE? NO YES
BELL OUTPUT: 0
BELL ACTION . . . . .
FIRE TYPE: T
SUPRVSRY TYPE: N
CO TYPE: 4
OUTPUT OPTIONS
