Battery Supervision
The panel tests the battery when AC power is present. The test is done every three minutes and lasts for five seconds.
During the test, the panel places a load on the battery. If the battery voltage falls below23.4VDC a low battery is
detected. If AC power is not present, a low battery is detected any time the battery voltage falls below23.4VDC. When
battery voltage drops below20VDC, the panel performs a battery cuto to prevent deep discharge damage.
If a low battery is detected with AC power present, the test repeats every two minutes until the battery charges
above24.6VDC. If a weak battery is replaced with a fully charged battery, the restored battery will not be detected until
the next test is completed.
POWER REQUIREMENTS
During AC power failure, the XF6 Series panel and all connected auxiliary devices draw their power from the battery. All
devices must be taken into consideration when calculating the battery standby capacity. The following table lists the
XF6 Series panel power requirements. You must add the additional current draw of keypads, zone expansion modules,
smoke detector output, and any other auxiliary devices used in the system for the total current required. The total is then
multiplied by the number of standby hours required to calculate the total ampere-hours required.
Standby Battery Power Calculations Standby Current Alarm Current
XF6 Series Fire Control Panel
7830F Fire Command Keypad
Relay Outputs (ON)
Switch Grounds (ON)
Active Zones
NAC Zones
2-Wire Smoke Detectors
Qty 1
Qty _______
Qty _______
Qty _______
Qty _______
Qty _______
Qty _______
x
x
x
x
x
x
x
90 mA
84 mA
3 mA
7 mA
7 mA
mA
mA
______mA
______
______
______
______
______
______
Qty 1
Qty _______
Qty _______
Qty _______
Qty _______
Qty _______
Qty _______
x
x
x
x
x
x
x
102 mA
108 mA
3 mA
61 mA
7 mA
mA
mA
______mA
______
______
______
______
______
______
263LTE Cellular Communicator Qty _______ x 12 mA ______ Qty _______ x 12 mA ______
1100X Wireless Receiver Qty _______ x 15 mA ______ Qty _______ x 21 mA ______
1100XH Wireless High Power Receiver Qty _______ x 45 mA ______ Qty _______ x 61 mA ______
860 Relay Output Module (one relay active)
All four relays active
Qty _______ x 20 mA
83 mA
______
______
Qty _______ x 20 mA
83 mA
______
______
865 Class A or B Notification Module Qty _______ x 16 mA ______ Qty _______ x 51 mA ______
866 Class B Notification Module Qty _______ x 27 mA ______ Qty _______ x 46 mA ______
867 LX-Bus Class B Notification Module Qty _______ x 18 mA ______ Qty _______ x 52 mA ______
7830F Fire Command Keypad Qty _______ x 84 mA ______ Qty _______ x 108 mA ______
630F Remote Fire Command Center Qty _______ x 38 mA ______ Qty _______ x 55 mA ______
7070/7170 Thinline/7070A Aqualite Keypad
Active Zones (EOL Installed)
Qty _______ x 43 mA
1 mA
______
______
Qty _______
Qty _______
x
x
52 mA
1 mA*
______
______
7073/7173 Thinline/7073A Aqualite Keypad
Active Zones (EOL Installed)
Qty _______ x 51 mA
1 mA
______
______
Qty _______
Qty _______
x
x
60 mA
1 mA*
______
______
Copy Sub-Totals to next page Sub-Total Standby ______ mA Sub-Total Alarm
______ mA
*
Based on 10% of active zones in alarm.
