multiple 716 Output Expander Modules. In addition, 45 wireless outputs are available when
using the 1100X Series wireless receiver.
Select from the following output numbers:
• 1 to 6 — Onboard panel outputs
• 500 to 999 — LX-Bus output, Relay output, Zone expansion output
• G1 to G20 — Output group
* The response time of a wireless output is the time it takes for a wireless output to activate
once the panel event occurs. You determine whether a wireless output is a slow or fast
response based on the output number assigned. A slow response output number extends
battery life, but response time may be up to 15 seconds. A fast response output number
responds within 1 second, but reduces battery life. Refer to the specific wireless output
installation guide to determine battery life. Output response times are programmed in
Output Information.
Cuto Output
Outputs 1 to 6 can be entered here to turn o after a time specified in CUTOFF TIME. To
disable this option, press any select key or area to clear the display then press CMD. The
Cuto Output displays dashes when no outputs are selected.
Output Cuto Time
If a Cuto Output (1-6) is assigned, enter a Cuto Time of 1 to 99 minutes for the output to
remain on. Enter 0 (zero) for continuous output.
Communication Trouble Output
The Communication Trouble Output also turns on when NET is selected as the primary
communication method and NET communication fails after one minute. When NET
communication is restored the Communication Trouble Output automatically turns o.
To manually turn the output o, select O for the output number in the User Menu Outputs
On/O section. Enter 0 (zero) to disable this output.
Fire Alarm Output
Enter the Output/Favorite number to turn on when a fire type zone is placed in alarm. The
output is turned o using the Sensor Reset option while no additional fire type zones are in
alarm. Enter 0 (zero) to disable. This output is not compatible with Cuto Outputs.
Fire Trouble Output
Enter the output number to turn on when a fire type zone is placed in trouble, when a
supervisory type zone is placed in trouble, or when any system monitor (AC, Battery) is
placed in trouble. The output turns o when all fire and supervisory type zones, or system
monitors are restored to normal. Enter 0 (zero) to disable this output. This output is not
compatible with Cuto Outputs. This output can be connected to a lamp, LED, or buzzer
using the DMP Model 716 Output Expansion Module.
Device Fail Output
Enter the output number to turn on when an addressed device fails to respond to polling
from the panel. A Missing Device report is sent to the receiver and is stored as an event in
the panel. The output is turned o when the device responds to polling or is removed from
programming in the system. Enter 0 (zero) to disable this output and LX-Bus™ device fail
reporting to the receiver. If any addressed device is unsupervised, this output cannot be
used.
Sensor Reset Output
Enter the output/Favorite number to turn on when a Sensor Reset is performed at a
keypad. The output turns o automatically 5 seconds later. This function can be used to
reset smoke detectors that are operated by an external power supply through a Model 716
Output Expander Module. Enter 0 (zero) to disable this output.
CO OUTS: - - - - - -
CUTOFF TIME: 0
COM FAIL OUT: 0
FIRE ALR OUT: 0
FIRE TRB OUT: 0
DVC FAIL OUT: 0
SNSR RST OUT: 0
