Digital Monitoring Products XF6 Series Installation and Programming Guide
36
1-6 and LX-500-599 available. XF6-500 panels have onboard zones 1-6 and LX-500-999
available. Available zone numbers are shown in the table below.
Panel Programming Zone Number
Onboard 1-6
Keypad Bus Programming Zone Number
1 11-14
2 21-24
3 31-34
4 41-44
5 51-54
6 61-64
7 71-74
8 81-84
9 91-94
10 101-104
11 111-114
12 121-124
13
131-134
14 141-144
15 151-154
16 161-164
LX-Bus Programming Zone Number
LX-Bus 500 500-599
LX-Bus 600 600-699
LX-Bus 700 700-799
LX-Bus 800 800-899
LX-Bus 900 900-999
Press CMD to enter a zone name.
Zone Name
Zone names can have up to 32 alphanumeric characters. A name must be given to each
zone in the system. The name can display at the keypads. A zone that is not part of the
system must be marked unused.
To add a zone name to the system, press any select key or area and then enter up to 32
characters for the new zone name. Press CMD to continue.
To mark a zone unused, de lete the old name by pressing any select key or area, then press
CMD. The pro grammer auto matically pro grams the name as * UNUSED *. If you have
already cleared Zone Information during Initialization, the zones is marked * UNUSED *.
Zone Type
The panel contains 4 default zone types for use in configuring the system. These zone
types provide the most commonly selected functions for their applications. All zone types
can be customized by changing the options listed below.
The Zone Type defines the panel response to the zone being opened or shorted. This is
called the Alarm Action. There are up to 7 possible alarm action responses depending on
the zone type and any restrictions it may have. See the Zone Type chart in the Appendix.
When you assign a Zone Type to a zone, automatic alarm actions are made.
To enter a new Zone Type, press any select key or area. The display lists all of the available
Zone Types.
Fire, Fire Verify, Supervisory, Carbon Monoxide (CO) zones are 24-hour zones.
Fire Bell Output
* UNUSED *
ZONE TYPE: FIRE
FI SV FV CO
FIRE BELL OUT: 0
