Digital Monitoring Products XF6 Series Installation and Programming Guide
26
Sends system monitor reports, such as AC and battery, and system event reports.
Supervisory Reports also sends the following reports:
• Alarm Bell Silenced
Entré Checkin
Select the rate at which check-in messages are sent over the Entré connection. Select 0
(zero) to disable check in messages. Range is 0, 3-240 minutes. Default is 0.
Entré Passphrase
To enable encryption enter an 8 to 16-character Passphrase using alphanumeric characters.
If you leave the Passphrase blank, the panel communicates with Entré, but the data is not
encrypted. The Passphrase is BLANK by default.
Integrator Connection
This option displays if the panel has network or cellular capability. Select NET to allow a
dedicated network connection with the integrator. Options are NONE or NET. Default is
NONE.
Integrator Incoming TCP Port
This option displays only if NET is chosen for the integrator connection. Enter the
programming port number for the incoming connection. The programming port identifies
the port used to communicate messages to and from the integrator software. This port
cannot be the same port as programmed in Network Programming Port. The default
Programming Port setting is 8011.
Integrator IP Address
This option displays only if NET is chosen for the integrator connection. Enter the
integrator IP address where the panel sends network messages. The integrator IP
Address must be unique and cannot be duplicated on the network. The periods display
automatically. Default is 0.0.0.0.
Integrator Outbound TCP Port
This option displays only if NET is chosen for the integrator connection. Enter the
programming port number for the outbound connection. The programming port identifies
the port used to communicate messages to the integrator software. Default is
8001.
Integrator Backup Connection
This option displays if NET or CELL is chosen for the integrator connection. Enter the
backup address where the panel sends network messages if the first integrator connection
fails. The connection must be unique and cannot be duplicated on the network. If the
backup connection is NET, enter all 12 digits and leave out the periods. For example, enter
IP address 192.168.0.250 as 192168000250. The periods display automatically. Default is
0.0.0.0.
Integrator Backup TCP Port
This option displays only if NET is chosen for the integrator connection. Enter the backup
programming port number for the outbound connection in case the connection to the
primary IP fails. Default is 8011.
Integrator Reports
This option displays only if NET is chosen for the integrator connection. Choose which
types of system reports are sent to the integrator. Press CMD to view all of the integrator
report options. Choose YES to enable zone, user code, or supervisory message reports. All
reports default to YES.
Zone Reports
Sends changes in the status of active zones. Includes the zone number, name, type, the
action (alarm, trouble, bypass, etc.), and user number (if applicable). If performing a Walk
ENTRE CHECKIN
MINUTES: 0
ENTRE PASSPHRASE
-
INTEGRATOR
CONNECTION: NONE
INTGRTR INCOMING
TCP PORT: 8011
INTEGRATOR IP
0.0.0.0
INTGRTR OUTBOUND
TCP PORT: 8001
INTGRTR BACKUP IP
-
INTGRTR BKUP TCP
PORT: 8011
INTGRTR REPORTS
ZONE: NO YES
