program. When using the contacts, you must use consecutive zone numbers. Default is
Contact 1.
Already In Use message displays when the Contact is already programmed for another
zone. The programmed zone number displays.
When EXT is selected as the Contact type, external devices connected to the 1103 terminal
block, select NO to use normally closed (N/C) contacts. Select YES to use normally open
(N/O) contacts. Default is NO.
Supervision Time
Press any select key or area to select the supervision time required for the wireless zone.
Press CMD to accept the default time. Default is 240 minutes.
Refer to the Wireless Check-in and Supervision Time Definitions section of the Appendix
for supervision information.
Press the select key or area under the required number of minutes. The transmitter must
check in at least once during this time or a missing condition is indicated for that zone.
1100 Series transmitters automatically checkin based on the supervision time selected
for the wireless zone, no additional programming is needed. If two zones share the same
transmitter, the last programmed supervision time is stored as the supervision time for
both zones. Zero (0) indicates an unsupervised transmitter.
When the panel is reset or a receiver is installed or powered down and powered up, the
supervision timer restarts for all wireless zones.
Alarm Action
This option allows you to change any Zone Type standard definitions. When the Zone Type
is specified, the Alarm Action for that zone is stored in memory.
Output Number
You can specify any of the Relay Outputs on the panel to be activated by a zone condition
(1 to 6, 500 to 999 if Model 716 used, G1 to G20). The output can be activated regardless of
the report to transmit or whether or not the zone is programmed as local.
To enter an output number, press any select key or area followed by the output number.
Press CMD.
Output Action
Output Action allows you to assign an output action to the relay: Steady, Pulse, Momentary,
or Follow. Default is STEADY.
STEADY - The output is turned on and remains on until an output cuto time expires, or
the output is reset from the keypad menu.
PULSE - The output alternates one second on and one second o.
MOMENTARY - The output is turned on only once for one second.
FOLLOW - The output is turned on and remains on while the zone is in an o normal, or
bad condition. When the zone restores, the output is turned o.
Swinger Bypass
Selecting YES allows the zone to be swinger bypassed by the panel according to the
specifications pro grammed in Swinger Bypass Trips and Reset Swinger Bypass. The Bypass
condition displays in the keypad Status List. Selecting NO disables swinger bypassing for
this zone.
If within one hour, a zone trips the total number of times as specified in Swinger Bypass
Trips, the panel bypasses it until one of the following conditions occur;
• The zone remains normal for one hour and the Reset Swinger Bypass is YES.
ALREADY IN USE
ZONE NUMBER: XXX
ZONE INFORMATION
NORM OPN NO YES
TRANSMITTER
SUPRVSN TIME: 240
SELECT MINUTES:
0 3 60 240
ALARM ACTION . . . .
OUTPUT NO: 0
OUTPUT: STEADY
STD PLS MOM FOLW
SWGR BYP NO YES
To Next Page
