Digital Monitoring Products XF6 Series Installation and Programming Guide
22
Time if the primary path becomes unavailable. This option also indicates a Communication
Trouble (S10) if the cell tower is unavailable for 3 minutes.
When YES is selected, enter the number of minutes between check-in reports, from 2 to
240 for NET or 4 to 240 for CELL.
Fail Time
This option displays if CHECKIN is set to YES. Entering a FAIL TIME allows the receiver to
miss multiple check-ins before logging that the panel is missing. The maximum fail time is
240 minutes. For example, if CHECKIN is 10 and FAIL TIME is 30, the receiver only indicates
a Panel Not Responding after 30 minutes. The FAIL TIME must be equal to or greater than
the CHECKIN time. Default is 60 for NET and CELL.
Receiver IP
This option displays if the Communication Type is NET or CELL. Enter the Receiver IP
address where the panel sends network messages. The Receiver IP Address must be
unique and cannot be duplicated on the network. Enter all 12 digits and leave out the
periods. For example, enter IP address 192.168.0.250 as 192168000250. The periods display
automatically.
Receiver Port
Enter the receiver port number. Valid range is 1 to 65,535. Default is 2001.
Advanced Programming
Select YES to enter the Advanced Programming menu for the communication
path currently being programmed. Selecting NO ends programming of the current
communication path and takes users back to the Communication Path option to program a
secondary path.
Fail Test Hours
This option sets the frequency for a Backup or Adaptive path to send a test report when
the closest previous path fails within its path group.
If Fail Test Hours is set to 0, test reports are sent only according to Test Report
programming. Range is 0 to 24 hours. Default is 0.
Protocol
This option displays only if Communication Type is NET.
Select TCP to communicate over the network using TCP protocol. Select UDP to
communicate using UDP protocol. Default is TCP.
Retry Seconds
This option displays only when Communication type is NET.
Enter the number of seconds (between 6 and 15) the panel should wait before retrying to
send a message to the receiver if an acknowledgment was not received. The panel retries
as many times as possible for a period of one minute before sending a network trouble
message. The default Retry Time is 6 seconds.
Duplicate Alarms
This option displays for BACKUP paths. If Yes is selected, the current backup path
duplicates all alarms occurring on its group primary path. Default is NO.
Send Path Information
This option displays for each path and if YES, each panel message includes path
information such as path number, communication type, and path type. Default is NO.
NETWORK OPTIONS
CHECKIN MINS: 58
FAIL MINS: 60
RECEIVER IP
0.0.0.0
RECEIVER PORT
2001
ADVANCED? NO YES
FAIL TEST HRS: 0
PROTOCOL: TCP
RETRY SECONDS: 6
DUPLICATE ALARMS
NO YES
SEND PATH INFO:
NO YES
