XF6 Series Installation and Programming Guide Digital Monitoring Products
43
Loader Version
This display is for factory use only. Press any select key or area to display the factory Loader Version. Press CMD to view
the next option.
Current Flash
This option displays Flash 1 or Flash 2 indicating which physical flash chip the panel is currently using. Press select key or
area to display the current flash information. Press CMD to view the next option.
Communication Status
This option tests the individual components of cellular or network communication. The displayed results are shown
below.
Cellular Results:
Successful Display Failure Display
MODEM OPERATING NO MODEM FOUND
IDENTIFIED NO SIM CARD
TOWER DETECTED NO TOWER
REGISTERED NOT REGISTERED
This displays the cellular signal strength of the nearest tower for the SIM card carrier.
The
▐
’s represent the signal strength 0-7. Select YES to continue through the remaining
component tests. Select NO to stop testing and return to the COMM STATUS option.
Successful Display Failure Display
CONNECTED
CONNECT ERROR
NOT ACTIVATED
COMM PATH GOOD NO ACK RECEIVED
Network Results:
Successful Display Failure Display
LINK OK LINK ERROR
DHCP OK DHCP ERROR
GATEWAY FOUND NO GATEWAY
DEST FOUND NO DESTINATION
COMM PATH GOOD NOT CONNECTED
NO ACK RECEIVED
USING THE WALK TEST
The panel provides a walk test feature that allows a single technician to test the protection devices connected to zones
on the system. Conduct the Walk Test within 30 minutes of resetting the panel. The Walk Test automatically ends if no
zones are tripped for 20 minutes. TEST IN PROGRESS displays at all keypads When five minutes remain, TEST END
WARNING displays.
Walk Test
To conduct the Walk Test, reset the control panel by momentarily placing a jumper on
RESET. From the keypad, enter the code 8144.
The keypad displays WALK TEST for four seconds. If the system is monitored and the
SIGNAL: ▐▐▐▐▐▐▐
CONTINUE? NO YES
WALK TEST
To Next Page
