ES 250 PRO/ES 250 PRO FST
ES 400 PRO/ES 400 PRO FST
Mounting instructions
6.2.1 Multiport default settings
The keys on the control unit can be used to select one of the following
configurations (Parameter “FF”).
Configuration Multiport Function Input activation level
Standard (1) 1 Exit Status “Door closed”
2 Exit Doorbell contact
3 Input
Emergency stop/
emergency open
Low active/normally
open
4 Input Night/bank
Low active/normally
open
Status (2) 1 Exit Status “Door closed”
2 Exit Doorbell contact
3 Exit Info or malfunction
4 Exit Status “Door open”
Pharmacy (3)
1 Exit
Status “Door closed
and locked”
2 Exit Doorbell contact
3 Exit Info or malfunction
4 Input Pharmacy
Low active/normally
open
6.2.2 Possible functions
The following functions can be configured via the OSI.
Exit • Status “Door closed”
• Status “Door open”
• Malfunction
• Status “Door closed and
locked”
• Info and malfunction
• Position greater
• Lock alarm
• Doorbell contact
• Status “No faults in unit”
• Lock interlock
• Interlock impulse transmission
Input • Pharmacy
• Panic lock
• Night/bank
• Key switch 1 left
• Key switch 1 right
• Fire brigade switch
• Close dead man’s switch
• Open dead man’s switch
• Opening impulse via key
• Emergency stop
• Emergency open
• Soft reset
• Lock interlock
• Interlock impulse transmission
• Inside detector
• Outside detector
• Fire protection closures
Note
The panic lock, emergency stop, interlock and inside detector inputs are
not available on FST units.
Note
The interlock functions are only available via the I/O.
