Dormakaba ES 250 PRO - Page 56

56
WN 059677 45532 - 11/2023
ES 250 PRO/ES 250 PRO FST
ES 400 PRO/ES 400 PRO FST
Mounting instructions
6.2.3 Connection on the multiports
For multiport default setting
“Standard”
24VDC doorbell connection
Fig.89
1
3
io1
io2
io3
io4
24VDC GND
Doorbell connection with separate
power supply unit
Fig.90
1
3
io1
io2
io3
io4
NO
NC
C
In
24 V
Potential-free relay
contact
Item no.:
16732401150
Connection for “Door closed” message
24VDC
Fig.91
1
3
io1
io2
io3
io4
Connection for “Door closed” message
potential-free
Fig.92
1
3
io1
io2
io3
io4
NO
NC
C
In
24 V
Potential-free relay
contact
Item no.:
16732401150
Emergency stop/emergency open
connection
Fig.93
1
3
io1
io2
io3
io4
Night/bank connection
Fig.94
1
3
io1
io2
io3
io4
