131 10099206-AA
Fitting the new printhead (Combined)
1
Push the printhead forward into into the
print module locking mechanism
2
While pushing it forwards, rotate the
printhead upward towards the latch
3
Make sure the printhead is locked into
position
4
Connect the printhead ribbon cable to the
appropriate connector
Maintenance
