Dover markem-image SmartDate X65 - Print Features

Printer conguration
68 10099206-AA
Name: Head Out Time:
Range: 1 - 100
Default: 35
The time allowed for the printhead to move from the rest position
to print position
Name: Image Not Ready Action
Default: Raise Warning
The action to take if an ‘Image not Ready’ problem is detected
Name: Leading Edge Boost
Range: 50 - 140
Default: 100
Adjusts the power supplied to the printhead at the start of each
print
Name: Missed Line Fault Threshold
Range: 0 - 5000
Default: 0
For Markem-Imaje use only
Name: Print Darkness
Range: 80 - 120 (140)
Default: 100
The energy level supplied to the printhead for each print
Name: Print Darkness Adjust
Range: -25 - +25
Default: 0
Used as a permanent offset for differences in print quality
between SmartDate printers
Name: Start Border
Range: 0 - 20
Default: 4.0
The distance travelled by the printhead on the print anvil/roller
before printing starts
Print Features
Tools > Settings > Printer > Printing > Print Features
Setting Description
Name: Max Substrate Speed
Range: 1 - 1000 mm/s
Default: 600
The maximum linear speed the substrate will reach during
production
Name: Min Print Speed
Range: 0 - 200
Default: 70
The minimum speed the SmartDate will attempt to print
Name: Print Mode
Default: High Pack Rate
The print mode being used
Name: Relative Print Max Travel
Range: 0 - 30
Default: 0.0
The maximum amount (in mm) the printhead is allowed to move
when using the ‘Relative Motion’ feature
Name: Return Speed
Range: 100 - 600
Default: 600
The speed at which the printhead carriage or shuttle returns to
the home position
Name: Ribbon Save Mode
Default: No Ribbon Save
Enables the specied ribbon save feature
