Dover markem-image SmartDate X65 User Manual

Printer conguration
69 10099206-AA
Print Position
Tools > Settings > Printer > Printing > Print Position
Setting Description
Name: Maximum Print Width
Range: 0 - 55 (128)
Default: 55 (128)
Sets the maximum width of print. Usually used in conjunction with
Radial Ribbon Save
Name: Offset:
Range: 0 - 53
Default: 0
Moves the print across the target area
Name: Pre-Print Delay
Range: 0 - 99
Default: 0
Inserts a delay after the print trigger is received to ensure the
substrate is stationary before printing
Name: Print Position Tolerance
Range: 0 - 10
Default: 2
Denes (in mm) the limits of the target area on the substrate. A
lower value increases the print position accuracy at the expense
of using more ink ribbon
Name: Registration
Range: 0 - 600
Default: 0
The amount of substrate allowed to pass after a print trigger is
received in continuous applications
The amount the printhead is moved after a print trigger is
received in intermittent applications
Name: Registration Adjust
Range: -10 - +10
Default: 0
Permanent offset for when there are differences in registration
between SmartDate printers in a multi-line application
Name: Rotation
Range: 0° - 270°
Default: 0°
Denes the orientation of the print
 Display
Print Preview
Tools > Settings > Printer > Display > Print Preview
Setting Description
Name: Preview Rotation
Range: 0° - 270°
Default: 0°
The orientation of the preview displayed on the user interface
Name: Display Dead Dots
Default: Yes
Denes wether the dead dot feature is active on the print preview
screens of the user interface
