Technical Data
100
Instructions for use D-Vapor/D-Vapor 3000
Classifications
Classification according to EC Directive
93/42/EEC, Annex IX
Class II b
UMDNS-Code
Universal Medical Device Nomenclature
System – Nomenclature for medical products
10-144
Protection class according to IEC 60601-1 Class I
IP protection class IPX1
Ambient conditions
During operation
Temperature 18 to 30 °C (64.4 to 86 °F)
Atmospheric pressure 700 to 1100 hPa (10.2 to 16 psi)
Relative humidity 30 to 75 %, non-condensing
During storage and transport
Temperature –20 to 60 °C (–4 to 140 °F)
Atmospheric pressure 115 to 1100 hPa (1.7 to 16 psi)
Relative humidity 5 to 95 %, non-condensing
Performance characteristics
The D-Vapor is calibrated at a temperature of
22 °C (71.6 °F) and an atmospheric pressure of
1013 mbar (14.7 psi).
Carrier gas: Air, flow: 2.5 L/min
Concentration range 2 to 18 Vol%
Scale
2 to 10 Vol% 1 Vol% divisions
10 to 18 Vol% 2 Vol% divisions
Flow range 0.2 to 15 L/min (STPD)
Direction of flow According to arrow on rear of vaporizer
Required quality of the gases Clean, medically pure mixtures of O
2 and Air or O2
and N2O
Oil content <0.1 mg/m
3
Particle size Dust-free air (filtered with pore size <1 µm)
