Instructions for use D-Vapor/D-Vapor 3000 25
System overview
Symbols
Symbol Description
Follow the instructions for use
Caution! Observe accompany-
ing documents
Caution! Observe accompany-
ing documents
Warning! Strictly follow these in-
structions for use.
Connection for potential equal-
ization
2; 3; 4;... Concentration scale on the con-
trol dial of the Vaporizer for val-
ues up to and including
10 Vol%.
Concentration numbers on the
vapor control dial indicating the
dangers of a high output con-
centration and a restricted flow
range
On rear of the vaporizer and on
the connector, indicates direc-
tion of flow of the vaporizer
0 On the pushbutton for locking
the control dial.
Control dial position 0 (zero set-
ting), see page 30
Control dial position T (transport
setting), see page 30
D, DES
(D-Vapor)
Des., DES
(D-Vapor 3000)
On control dial
Abbreviation of the anesthetic
agent for which the vaporizer is
specified and calibrated
min. Minimum permissible filling lev-
el on the sight glass
max. Maximum permissible filling lev-
el on the sight glass
Operating Instructions
Read
Instructions
Caution!
12 14 16 18
T
Vol% Volume percent, indicates con-
centration unit
Vol Volume
Audio
paused 2 min
Suppress audible alarm for
2 minutes
Information for disposal
Fuse
Alternating current
Part number
Serial Number
Manufacturer
20xx Date of manufacture
IPX1 Level of protection from ingress
of water
Maximum weight of the vaporiz-
er
Use by
Temperature limitation
Relative humidity
Atmospheric pressure
Keep dry
Caution, fragile
Device is not approved for use
in MR environments
Symbol Description
REF
SN
