Dräger D-Vapor

Operation
58
Instructions for use D-Vapor/D-Vapor 3000
Test results
If all the corrected measured values are within the
permissible range:
The vaporizer may be put into operation.
After the test
If the vaporizer is on an anesthesia workstation:
 Switching off the vaporizer: Engage the control
dial in the 0 position.
If the vaporizer is not on an anesthesia workstation:
 Press the 0 button and set the control dial to the
T position. With plug-in adapter, engage locking
lever in control dial.
 Shut off the Air flow.
Example of a concentration check
Test of a desflurane vaporizer at the 8 % setting
– The measured value is 8.58 Vol%.
Monitor display is in Vol%, therefore no
correction.
– According to the chapter "Technical Data", the
permissible range of the vaporizer is ±15 % of
the set value, i.e. 6.8 to 9.2 Vol%.
The technical data for the anesthetic agent
monitor lists an accuracy of ±5 % rel. For a
measured value of 8.58 Vol%, this results in a
tolerance of ±0.43 Vol%.
The permissible range is increased by this
amount to a value of 6.37 to 9.63 Vol%.
– The measured value of 8.58 Vol% is in the
permissible range.
WARNING
Risk of injury to the patients
If the corrected measured values are not with-
in the permissible range, do not use the vapor-
izer.
Have the vaporizer checked by service per-
sonnel. Check the anesthetic agent monitor.
