AUXILIARY INPUTS, auxiliary inputs can be user configured and will display the message as
configured in the module.
Example
Alarm
Warning
Bearing temp high
LOW FUEL LEVEL, will be displayed if the fuel level detected by the fuel level sender falls below
the low fuel level setting.
Alarm
Warning
Low fuel level
LOW ENGINE TEMPERATURE, if the module detects that the engine coolant temperature has
fallen below the low engine temperature pre-alarm setting level, a warning will occur. Alarm Warning
Low Coolant Temp will be displayed.
Alarm
Warning
Low Coolant Temp
GENERATOR HIGH CURRENT, if the module detects a generator output current in excess of the
pre-set trip a warning is initiated. Alarm Warning High Current will be displayed. If this high current
condition continues for an excess period of time, then the alarm is escalated to a shutdown
condition. For further details of the high current alarm, please see High Current Shutdown Alarm.
Alarm
Warning
Over current
GENERATOR FAILED TO OPEN, if the module requests the generator contact/breaker to open it
will monitor the auxiliary contacts for feedback that this has happened. If the feedback does not
confirm the action within the Generator breaker open timer, then the following alarm will occur.
Alarm
Warning
Gen failed to open
